DIFFERENCE BETWEEN MIP,VIP AND DIP IN JUNIPER

Rashmi Bhardwaj | Blog,BUZZ,Routing & Switching
Advertisements

difference-between-mipvip-and-dip-in-juniper



Juniper ScreenOS platform supports Source NAT as well as Destination NAT and hence utilizes following terminologies – MIP , VIP and DIP.

The abbreviation for each term is –

  • Mapped IP (MIP)
  • Virtual IP (VIP)
  • Dynamic IP (DIP)

An MIP maps one external IP address to one internal IP address and does not alter the port information. A VIP maps one external IP address and one external port to a multiple number of possible IP addresses and ports. It can also translate external port to same or different internal port. DIP can enable policy-based NAT, and NAT, before VPN encapsulation; in which overlapping private IP addresses exist in a VPN network. Notable is that VIP and DIP is unidirectional whereas MIP is bidirectional.

Advertisements

Below comparison table will differentiate between MIP,VIP and DIP terms used in ScreenOS –

PARAMETER

MIP

VIP

DIP

Philosophy A one-to-one mapping of one address to another.                                                                                                                                                                                                                  a A virtual IP (VIP) address maps traffic received at one IP address to another address based on the destination port number in the TCP or UDP protocol                                          s A dynamic IP (DIP) address pool is a range of IP addresses from which the device can dynamically take addresses to use when performing NAT on the source IP address of outgoing or incoming IP packets.
NAT Type Destination NAT and Source NAT Destination NAT Source NAT
Usage Static NAT to/from Servers Outgoing NAT instead of using egress Interface IP Port forwarding to Servers
Port usage No Yes Yes
Mapping Type One-to-One One-to-Many One-to-Many and Many-to-One
Flow Direction Bidirectional.Traffic can be initiated from inside source or Outside Source Unidirectional.Traffic can be initiated from inside source only for VIP to take effect Unidirectional.Traffic can be initiated from outside source only for DIP to take effect



References –

https://kb.juniper.net/InfoCenter/index?page=content&id=KB6085
