CISCO AND HUAWEI EQUIVALENT COMMANDS

Below is list of commands generally used in Cisco platforms and their equivalent Huawei CLI command set. This is quite helpful especially for Cisco networking Engineers who face challenge when introduced to a new Huawei device for configuration –

CISCO COMMAND

HUAWEI COMMAND

ping ping
traceroute tracert
show display
show interfaces display interface
Show ip route display ip routing-table
Show ip interface Display ip interface
Show version Display version
Show ip bgp Display bgp routing-table
Show clock Display clock
Show port Display port-mapping
Show flash dir flash: (on user view mode)
Show logging Display logbuffer
Show snmp Display snmp-agent statistics
Show frame-relay pvc Display fr pvc-info
Show users Display users
Show terminal length screen-length disableundo screen-length disable
enable super
disable Super 0 (number is privilege level from 0 to 3,where 3 is default and equivalent to “enable” on Cisco)
Conf t System-view
exit quit
end return
Show policy-map interface Display qos policy interface
 send send (on user view mode)
 write terminal (sh run) display current-configuration
Sh startup Display saved-configuration
[no equivalent: shows the files used for startup] Display startup
Write erase Reset saved-configuration
Write mem (or wr or copy run start) save
clear counters reset (on user view mode)Reset counters interface
telnet telnet
 Enable secret (conf mode) Super pass cipher (system mode)
 Term mon term debu
clock clock
 no undo
 debug / no debug debugging / undo debugging
copy running-config Save safely
terminal monitor terminal monitor
terminal length screen-length disableundo screen-length disable
terminal no monitor undo terminal monitor
clear counters reset counters interface
 clear interface  reset counters interface
 clear crypto ipsec saike sa
 clear access-list counters  reset acl counter all
 reload  reboot
 shutdown  shutdown
 boot  boot bootrom
 Aaa  hwtacacs scheme
 terminal no monitor  undo terminal monitor
 tacacs-server  hwtacacs scheme (in conf command)
 snmp-server  tftp-server (in conf command)
 router bgp bgp
 Router rip rip
 ip tacacs  hwtacacs nas-ip (this command doesn’t exist !!!)
 mtu  Mtu (this command doesn’t exist !!!)
 clear ip cef  reset ip fast-forwarding
 clear ip route *  reset ip routing-table statistics protocol all
 Clear ip bgp  Reset bgp all
 Show tech  display diagnostic-information
 Sh ip nat translation  Display nat session
 Show Controller  display controller (but not relevant for non-modularchassis)
 show dsl int atm 0  display dsl status interface Atm 2/0
 sho atm pvc  Display atm pvc-info
 debug pvc nego  Debug atm all (very dangerous – might crash router)
 sho crypto isakmp sa  Display ike sa
 sho crypto isakmp key  Display ike peer
 sho crypto isakmp police  Display ike proposal
