HSRP VS VRRP

S No                                 HSRP                                   VRRP
  1 Cisco Propritory Open Standard
  2 RFC 2281 RFC 3768
  3 HSRP routers communicate via multicast hello packets to – 224.0.0.2 for version 1 – 224.0.0.102 for version 2. VRRP routers communicate via multicast IP address 224.0.0.18
  4 Separate IP Address needed for the Virtual If needed,VRRP can use the physical IP Address of the Virtual.
  5 One Master, One Standby and rest are listening One Master and all other routers are backup
  6 All virtual router use MAC address 0000.0c07.acXX where XX is the group ID. All virtual routers use 00-00-5E-00-01-XX as its MAC address
  7 Can track an interface for failover Failover by tracking interface Failover by tracking interface and IP address reachability.
